Rannie 77T and Gaulin 77T Series - High Pressure Homogenizers

Product Type(s): General Homogenizers

The more modular and flexible design of the APV 77T makes it suitable for a wide range of applications in dairy, food, beverage, industrial and pharmaceutical industries.

Integrated Rannie® and Gaulin® Homogenizer Enhancements

Advanced Power End for Reduced Ownership Costs

Combining the design features of our Rannie®, Gaulin® Liquid Ends, the new Power End with improved operator interface and controls simplifies routine maintenance with an emphasis on reliability in order to reduce total costs of ownership.

Operational Benefits

Optimal Operator Interface

All controls placed logically together
Gauges and other visual indicators are visible from the operating position
Direct view of key power end check points through a window
Modular electrical controls

High Reliability

Internal gear transmission
Enhanced oil treatment and cooling system with oil filter as standard
Low center of gravity for reduced vibration

Maintenance-Friendly Design

Easy access for servicing, reduced maintenance time
Low machine height for ergonomic access
Visual service indicators
Improved cooling and oil treatment indicators
Access to electric control box from the outside
Built-in belt tensioner

Noise Reduction

Balanced low speed crankshaft for reduced noise

Core Features

The Liquid End Includes

Pressure gauges
Pressure relief valve
Weld-stub product connections
3-A sanitary design in stainless steel or duplex materials
Ball or poppet pump valves
Hard metal coated long life plungers
Hydraulic valve actuator for smooth and stable control
Single or two stage homogenizing valve, to meet your application requirements

The Power End Includes

Internal gear and self-adjusting belt tightener
Oil cooling system with external plate heat exchanger and temperature transmitter
Oil filter including alarm

Other Standard Features

wired to stainless steel control cabinet
Emergency stop
Stainless steel sanitary cladding
Inspection window for key operating indicators
Set of tools
Set of packings

Key Applications

Field of Application

Dairy
Food
Beverage
Industrial
Pharmaceutical

Rannie model 77T / Three-Piece Valve Housing Poppet and Ball Valves

TYPE	US UNITS		METRIC UNITS
TYPE	CAPACITY GPH	PRESSURE PSI	CAPACITY LPH	PRESSURE BAR
75.95	3,550	2,175	13,500	150
70.95	3,100	2,500	11,800	170
65.95	2,650	3,000	10,150	210
45.95	1,320	5,800	5,000	400
25.95	265	17,400	1,000	1,200
22.95	210	21,750	800	1,500

Gaulin model 77T / Mono-Block Valve Housing Poppet and Ball Valves

TYPE	US UNITS		METRIC UNITS
TYPE	CAPACITY GPH	PRESSURE PSI	CAPACITY LPH	PRESSURE BAR
POPPET TYPE VALVES
2.0P	3,550	2,000	13,500	140
2.5P	3,100	2,500	11,750	170
3.0P	2,640	3,000	10,000	210
5.8P	1,320	5,800	5,000	400
BALL TYPE VALVES
2.0B	3,375	2,000	12,750	140
2.5B	2,940	2,500	11,100	170
3.0B	2,640	3,000	10,000	210
5.8B	1,190	5,800	4,500	400

Dimensions

Dimensions	Length in / mm	Width in / mm	Height in / mm	Weight (incl. motor) lbs. / kg
Standard machine	89 / 2,260	56.5 / 1,435	56 / 1,425	5,845 / 2,650
Packed in crate	118 / 3,000	71 / 1,800	71 / 1,800	6,725 / 3,050
STANDARD INCL. LOW NOISE EXTENSION	111 / 2,820	64 / 1,630	66 / 1,680	6,950 /3,150
Cubic measure of STANDARD crating: 9.72 m3

Options

Standard Options

Start/stop buttons
Alternative product connections e.g. tri-clamp, high-pressure outlet, dual inlet
Automatic hydraulic actuators and 4-20mA gauges for remote operation
Potentiometer-controlled electrical valves for hydraulic actuators
Plunger lubrication control package including flow switch and solenoid valve
Inlet pressure gauge with low pressure switch
Outlet pressure gauge or transmitter
Aseptic cylinder design
Sanitary pulsation dampener(s): inlet and outlet
Micro-Gap valve for increased efficiency and reduced energy consumption
Motor starter cabinet
Control cabinet with PLC or relay operation
Low-noise insulated extension for liquid end
Ceramic plungers
Choice of materials for cylinder block, pump valves, homogenzing valves, packings, etc.
Enhanced spare parts kit

Other Options in Request

Various enhanced liquid end block designs for special applications
Actuated pressure relief valve
Vibration sensors
Explosion-proof design
Electro-polished wetted parts
UFO – Oil Filtration system
Documentation packages for material traceability, certification and cGMP support
