PowerMon S Online Analyzer

Key Applications
  • Measuring of Total N and Total P

  • Measuring of DOC, CSB

  • Measuring of Messung von NH4-N / NO3-N / PO4-P

  • For waste water treatment plants, rivers, lakes and coastal waters

Dimensions

Technical Data



Measuring methods Potentriometric
Measuring cycle at least 6 min.
Measuring range

NO3 - 0 - 1 to 0 - 500 mg N/l
F- 0 - 1 to 0 - 1.000 mg/l
Cl- 0 - 0,1 to 0 - 10.000 mg/l
NH4 + 0 - 2,5 to 0 - 1.000 mg/l
K+ 0 - 1 to 0 - 10.000 mg/l
Further parameters and measuring ranges on request.

Precision typ. <5% of measuring range
(end of value)
Drift typ. <1% of measuring range
(end of value)
Reagent supply
for approx. 3 weeks
Number of measuring points max. 6
Output signal
  • 0/4-20 mA
  • max. load 500 OHM
  • characteristic curve:
    • linear/logarithmic
    • galvanically isolated
Interfaces

USB / Ethernet
Option:
modem: analog, GSM, ISDN, UMTS Profibus DP, Modbus RTU and TCP

Relay contacts

4/12 potential free contacts
free allocable
(e.g. alarm contact)

Digital inputs 4/12 e.g. activating and deactivating of measuring points, system control
Sample

pressure-free

Temperature: 15 - 45°C (288 - 318 K)

Flow: 3 – 10 l/h free from suspended matter and oil

Connection: tube, flexible

(ID 1.5 - 3 mm)

Drain pressure-free tube, flexible (ID 10 mm)
Power supply

85…264 VAC at 47…63 Hz

Power consumption:

~ 42 VA (max. 90 VA)

Environmental temperature 15 - 35°C (288 - 308 K)
Installation wall-mounted
Protection class (EN 60529)
  • IP 65 ( electronics )
  • IP 54 ( with housing )
  • IP 21 ( with jacket )
Weight

housing with reagent cabinet

53 - 60 kg without reagents

Dimensions

(HEIGHT X WIDTH X DEPTH)

housing: 700x600x320 mm

with reagent cabinet: 1100x600x354 mm
