Universal Twin Screw Series - Positive Displacement Pumps

Product Type:
Pumps / Positive Displacement Pumps

Universal Twin Screw Series pumps offer reliability, process flexibility, and smooth operation.

Features

Benefits

  • Reliable performance - Screws made from Waukesha Alloy 88 non-galling material allow the pump to run through incidental contact and reduce risk of pump damage if screws make contact
  • Gentle product handling - Pumps large particulates without degradation
  • Responsive service - Extensive global distribution network with certified repair centers provide quick response times for parts and service
  • Easy maintenance - Front loaded access to product side seals
  • Process flexibility - Low inlet pressure requirement and a wide range of operating speeds allow for multiple duties including process and CIP supply. Bi-directional flow capability without making modifications to the pump.
  • Smooth operation - Reduces slip pulse in low inlet pressure, low viscosity, and high pressure conditions
  • Reduced noise levels - Operating principle virtually eliminates pressure fluctuations
  • EHEDG (Type EL Class I) certification applies for UTS pump sizes 015 to 220 with EPDM, FKM or FFKM gaskets and SiC, TC or C mechanical seal material
Theory of Operation

Delivering Axial Flow with Gentle Product Handling


The Universal Twin Screw delivers axial flow with gentle product handling and the ability to pump shear sensitive fluids with larger particulates in lower pressure applications.

As the screws mesh together, they form multiple sets of “sealed cavities” which give the pump positive pressure capability to carry product from the inlet to the outlet in a smooth, consistent manner.

Three screw pitch options are available for all model sizes to provide users with a wide selection of pressure and flow rate profiles depending on application and particle size requirements.

Our widest pitch rotor has a smaller helical surface and is used for applications requiring lower pressures and higher flow rates

Our narrow pitch rotor has a larger helical surface and is used when applications require higher pressures and have lower flow rates.  The narrow pitch also provides the most optimal suction capacity.

The mid-range pitch offers a balance in pressure and flow velocities between the larger and smaller screw profiles.

Key Applications

Food & Beverage

  • Soups, Stews, Tomato Pastes
  • Vegetables, Dressings
  • Chocolate, Fats & Oils
  • Batters, Cream Fillings
  • Brewery, Wort
  • Soft / Fruit Drinks
  • Meat Processing





Dairy

  • Cream, Milk
  • Cheese Curd & Whey
  • Cottage Cheese
  • Yogurt





Pharmaceutical / Cosmetics

  • Pill Pastes
  • Syrups, Extracts, Slurries
  • Face Creams & Lotions
  • Hair Styling Gels & Liquids
  • Dyes & Alcohols
  • Soaps
  • Cosmetics





Chemicals / Industrial

  • Solvents, Paints
  • Fuels
  • Resins, Polymers & Sludges
  • Oil & Lubricants
Specifications

MODEL

SCREW
PITCH

DISPLACEMENT
PER REVOLUTION

NOMINAL
CAPACITY (MAX)

COVER PORT BODY PORT MAXIMUM PARTICULATE

MAXIMUM
PRESSURE
(MAX)

MAXIMUM RPM TEMP RANGE
015-UTS 16.5 0.02 Gal. (0.08 Liter) 70 GPM (265 LPM) 2" (51mm) 1.5" (38mm) 0.33" (8mm) 375 PSI (25.5 bar) 3500 -40°F (-40°C) to 300 (149°C)
33 0.03 Gal. (0.11 Liter) 105 GPM (398 LPM) 0.65" (18mm)
44 0.04 Gal. (0.15 Liter) 140 GPM (530 LPM) 0.44"* (11mm)
030-UTS 16.8 0.03 Gal. (0.11 Liter) 93 GPM (352LPM) 2.5" (64mm) 2" (51mm) 0.33" (8mm) 375 PSI (25.5 bar) 3100
28
0.05 Gal. (0.19 Liter)
155 GPM (587 LPM)
0.55" (14mm)
42 0.08 Gal. (0.30 Liter) 248 GPM (939 LPM) 0.83" (21mm)
130-UTS 36.7 0.12 Gal. (0.45 Liter) 300 GPM (1136 LPM) 4" (102mm) 2.5" (64mm) 0.72" (18mm) 375 PSI (25.5 bar) 2500
55 0.18 Gal. (0.68 Liter) 450 GPM (1703 LPM) 1.09" (28mm)
73.4 0.24 Gal. (0.91 Liter) 600 GPM (2271 LPM) 0.72"* (18mm)
220-UTS 45 0.30 Gal. (1.14 Liter) 600 GPM (2271 LPM) 4" (102mm)
or
6" (152mm)
4" (102mm)
or
6" (152mm)
0.89" (22mm) 375 PSI (25.5 bar) 2000
60 0.40 Gal. (1.51 Liter) 800 GPM (3028 LPM) 1.18" (30mm)
90 0.61 Gal. (2.31 Liter) 1220 GPM (4618 LPM) 1.77" (45mm)

* Double start screws limit particulate size.

NOTE: If operation is required near the maximum allowable RPM, please contact SPX FLOW application engineering for confirmation of the correct pump configuration.

Dimensions

MODEL 015-UTS

0-3500 RPM speed range. 2" (51 mm) cover port and 1.5" (38 mm) body port sizes; suitable to 375 PSI (25.5 bar) differential pressure. Temperature range -40°F (-40°C) to 300°F (149°C).



  A B C D
+.000 -.001
E F G H I COVER PORT BODY PORT WEIGHT
IN
16.40

15.32

10.27
0.875
4.95
7.68
7.28
11.84
1.40 1.50, 2.00 1.50, 2.00  87 lbs
MM
417
389
261
22.23
126
195
185
301
36 38, 51 38, 51  39 kg

NOTE: Dimensions are for guidance purposes only. Contact your SPX FLOW Representative if more detailed measurements are needed.

1 Shaft key dimension: .187 x .187 x 1.125 in / 5 x 5 x 29 mm

Approximate shipping weight 87 lb. (39 kg.)

MODEL 030-UTS

0-3100 RPM speed range. 2.5" (64mm) cover port and 2.0" (51mm) body port sizes; suitable to 375 PSI (25.5 bar) differential pressure. Temperature range -40°F (-40°C) to 300°F (149°C).


A
B
C D
+.000 -.001
E
F
G
H I COVER PORT BODY PORT WEIGHT
IN
20.11

18.07

11.83
1.25
4.95
9.65
6.96
12.49
1.58 2.00, 3.00 2.00, 2.50  160 lbs
MM
511
459
300
31.75
126
245
177
317
40 51, 76 51, 76  73 kg

NOTE: Dimensions are for guidance purposes only. Contact your SPX FLOW Representative if more detailed measurements are needed.

1Shaft key dimension: .250 x .250x 1.625 in / 6 x 6 x 41 mm

Approximate shipping weight 160 lb. (73 kg.)

MODEL 130-UTS

0-2500 RPM speed range. 4.0" (102mm) cover port and 2.5" (64mm) body port sizes; suitable to 375 PSI (25.5 bar) differential pressure. Temperature range -40°F (-40°C) to 300°F (149°C).



A
B
C D
+.000 -.001
E
F
G H I COVER PORT
BODY PORT
WEIGHT
IN
25.81

23.37

15.29
1.625
7.46
13.12
9.92
16.62 2.42 3.00, 4.00 2.50, 3.00 385 lbs
MM
656
594
388
41.28
189
332
252
422 61 76, 102 64, 76  175 kg

NOTE: Dimensions are for guidance purposes only. Contact your SPX FLOW Representative if more detailed measurements are needed.

1 Shaft key dimension: .325 x .325 x 1.750 in / 8 x 8 x 44 mm

Approximate shipping weight 385 lb. (175 kg.)

MODEL 220-UTS



0-2000 RPM speed range. 4.0" or 6.0" (102mm or 152mm) cover port and 4.0" or 6.0" (102mm or 152mm) body port sizes; suitable to 375 PSI (25.5 bar) differential pressure. Temperature range -40°F (-40°C) to 300°F (149°C).


A
B
C
D
+.000 -.001
E
F
G
H I COVER PORT BODY PORT
WEIGHT
IN
33.79

23.03

18.18
2.00
9.19
16.90
8.68
20.28 2.17 4.00, 6.00 4.00, 6.00  750 lbs
MM
858
585
462
50.8
233
428
220
515 55 102, 152 102, 152  340 kg

NOTE: Dimensions are for guidance purposes only. Contact your SPX FLOW Representative if more detailed measurements are needed.

1 Shaft key dimension: .500 x .500 x 1.875 in / 13 x 13 x 48 mm

Approximate shipping weight 750 lb. (340 kg.)



Options
Port Options



Sanitary Clamp (S-Line*, I-Line, Q-Line) Bevel Seat Optional European Types; DIN, SMS, RJT Optional Aseptic Ports:
1 - Steam In
2 - Steam Out

*S-Line standard. Contact SPX FLOW for available rectangular flange inlets.



Screw Pitches



Narrow Middle Wide



O-rings

Standard:  FKM Standard
Options:  Fluoroelastomer (FKM), EPDM, Fluoroelastomer (FFKM)



Seals

Single or Double Mechanical Seals Available

Mechanical seal material options:

  • Carbon
  • Silicon Carbide
  • Tungsten Carbide

Elastomer choices for O-rings:

  • Fluoroelastomer (FKM)
  • EPDM
  • FFKM
Tru-Fit®

Close coupled Tru-Fit® pump mounted on stainless steel base with stainless steel adaptors standard.

Features:

  • No shaft alignment necessary. No coupling guard required.
  • Special base design enhances cleanability.
  • Reduces overall length of complete unit by an average of 20-25%.
  • Average of 20-25 gear ratios available per horsepower.
  • Separate oil sump for gear reducer and timing gears.

Options:

  • 304 SS polished plate base.
  • NEMA or IEC frames available. Right angle reducer also available for
    additional space savings.
  • 1/2 through 60 horsepower drive options available.
  • Horizontal or vertical porting.
Videos
Universal Twin Screw Pump Animation
Universal Twin Screw Pump Maintenance Procedures
Universal Twin Screw Pump Rotor Nut Tool
Universal Twin Screw Pump Animation - Chinese
Universal Twin Screw Pump Maintenance Video - Chinese
Universal Twin Screw Pump Maintenance Video - Japanese
Drawings & Models
Model 015-UTS
Universal Twin Screw Model 015UTS 2.0 in cover port 1.5 in body port STEP
zip
Universal Twin Screw Model 015UTS 2.0 in cover port 1.5 in body port STUB STEP
zip
Model 030-UTS
Universal Twin Screw Model 030UTS 2.5 in cover port 2.0 in body port STEP
zip
Universal Twin Screw Model 030UTS 2.5 in cover port 2.0 in body port STUB STEP
zip
Model 130-UTS
Universal Twin Screw Model 130UTS 4.0 in cover port 2.5 in body port STEP
zip
Universal Twin Screw Model 130UTS 4.0 in cover port 2.5 in body port STUB STEP
zip
Model 220-UTS
Universal Twin Screw Model 220UTS 4.0 in cover port 4.0 in body port S-Line STEP
zip
Universal Twin Screw Model 220UTS 4.0 in cover port 4.0 in body port STUB STEP
zip
Universal Twin Screw Model 220UTS 4.0 in cover port 6.0 in body port S-Line STEP
zip
Universal Twin Screw Model 220UTS 4.0 in cover port 6.0 in body port STUB STEP
zip
Universal Twin Screw Model 220UTS 6.0 in cover port 4.0 in body port S-Line STEP
zip
niversal Twin Screw Model 220UTS 6.0 in cover port 4.0 in body port STUB STEP
zip
Universal Twin Screw Model 220UTS 6.0 in cover port 6.0 in body port S-Line STEP
zip
Universal Twin Screw Model 220UTS 6.0 in cover port 6.0 in body port STUB STEP
zip
