Cost-Effective, Versatile Mixing with Low CAPEX Investment

The Flex-Mix Liquiverter offers a flexible and reliable solution for high quality mixing, dispersion, recombination and reestablishment of soluble products into low to medium viscosity fluids. It provides a large dissolution capacity due to its free vortex and square shape and is a popular choice for use in reconstitution of dairy products like yogurt, Sweetened Condensed Milk, sugar syrup, dispersion of starch and hydrocolloid.

A cost-effective mixing solution offering high performance, high shear mixing for a wide variety of applications

The Flex-Mix Liquiverter offers exceptional value with a simple, yet versatile, mixing solution for batch applications up to 3,000 liters or continuous production up to 20,000 l/h. A high shear option for semi and continuous mixing applications ensures all product externally or internally recirculated will be exposed to high shear for enhanced mixing results. Maintenance is straightforward and helps optimize the total cost of ownership while reliable operation is enhanced through the use of a direct drive which reduces wear on spare parts.

Efficient Mixing Made Simple”

• Simple, hygienic design ensures reliable operation, maximized uptime, reduced operating costs and enhanced cleanability
• The mixer is easy to maintain as it is directly coupled to the motor and needs no belts or gearboxes that can wear during operation
• Exceptionally simple operation with little training required
• Low CAPEX solution
• Large dissolution capacity increases mixing efficiency
• High shear option results in smaller particle sizes and smoother emulsions
• Fully drainable tank helps improve hygiene and minimize waste
• Flushed double mechanical shaft seal with choice of materials to suit application
• Flexible options

How the Flex-Mix Liquiverter Vortex Mixing System Works

The mixing principle in the Liquiverter is based on vortex-driven blending. Its bottom-mounted impeller generates an axial flow within its square-shaped mixing tank, which ensures no forced rotation of liquids. Powder or particles are added from the top of the tank, which are carried by the liquid in the tank towards the vortex center. The free vortex sucks liquid downwards, collapsing it around the powder and forcing it towards the mixer head at the base. The corners of the tank act as baffles to improve power transfer from the mixer, creating a dynamic process response and creating an axial flow pattern. This provides uniformity in the fluid and better mixing control of vortex and removes the need for additional baffles, improving cleanability of the unit and enhancing food safety.

The Flex-Mix Liquiverter can be used for batch mixing, inline mixing over one or more hydration tanks, or continuous mixing. The high shear forces and turbulence throughout the mixing tank ensure effective and homogenous mixing for excellent final product results.

Key Applications

• Sweetened Condensed Milk
• Plant based drinks
• Skim milk 35%, 40%, 50% total solids
• Chocolate milk
• Recombined milk
• Juices
• Juice concentrates
• Dessert cream
• Soups
• Cacao
• Yogurt
• Ice cream
• Oat slurry
• Tomato concentrate
